Grade 9–College. This trinocular compound microscope is equipped with both widefield 10x/18-mm and 25x/18-mm eyepieces, along with SA plan achromatic 4x, 10x, 40x, and 100x (oil immersion) objective lenses. Field of view is 18 mm with a magnification range from 40x to 2,500x. Features double slide storage, carrying handle, power plug storage, color-coded aperture diaphragm indicator, and USB-C input. An included eyepiece adapter can be used as a standard 1x C-mount for a C-mount digital camera.

Product Details
Grade 9–College. Microscopy has just been made easier with this high-quality Stellar 1 Series trinocular compound microscope. It is equipped with both widefield 10x/18-mm and 25x/18-mm eyepieces, along with SA plan achromatic 4x, 10x, 40x, and 100x (oil immersion) objective lenses for flexible magnification preferences. Field of view is 18 mm with a magnification range from 40x to 2,500x. Designed for convenience and functionality, this microscope features double slide storage, a handy carrying handle, and a smart storage solution for the power plug. The color-coded aperture diaphragm indicator ensures precise control over lighting. With a USB-C input compatible with portable power banks, you can take your trinocular microscope anywhere. An included eyepiece adapter can be used as a standard 1x C-mount for a C-mount digital camera, transforming this into a digital microscope; Wolfe® C-Mount Adapter, 0.5x (item #591170) is recommended (sold separately). Instruction manual and dust cover are included.

Product Features

• Optical System: DIN** optical system; mechanical length, 160 mm; conjugate distance, 195 mm
• Head Type: Siedentopf trinocular head inclined at 30° and rotatable 360° for ergonomic viewing; single diopter adjustment; interpupillary distance adjustment, 48 to 75 mm
• Eyepieces: WF10x/18 mm and WF25x/18 mm (no pointer)
• Nosepiece: Reversed revolving nosepiece
• Objectives: SA plan achromatic objectives; 4x, 10x, 40x, and 100x (oil immersion)
• Magnification: 40x, 100x, 250x (with 25x eyepiece), 400x, 1,000x, and 2,500x (with 25x eyepiece)
• Stage: Double-layer coaxial mechanical stage with slide holder; size, 125 x 115 mm; travel area, 70 x 25 mm
• Condenser: Fixed N.A. 1.25 Abbe condenser (not focusable) with iris diaphragm; features aperture diaphragm indicator that is color coded
• Illumination: Brightfield LED illumination with 1-W LED light source with intensity control, 30-minute auto power off
• Focusing System: Coaxial coarse and fine focus with pinion gear system; focusing indication line to assist in quick image plane location
• Power Supply: External power adapter; 110 to 240 V
• Dimensions: 13-3/10 x 6-7/10 x 13-3/10"
• Weight: 9.4 lb
• Warranty: 5-year limited warranty; electrical components are covered for 1 year

**DIN: Deutsche Industrie Normen, an industry standard.
